Siemens ARCADIS Varic Operator's Manual

System Description
ARCADIS Varic
SPR2-310.620.30.02.02 31
of 44
Radiation release with the hand switch 0
The hand switch is used to remote control radiation release and image storage.
The hand switch can be connected on either side of the C-arm system.
(1) Key for saving images (hold down key for < 2 seconds) and scenes
(hold down key for > 2 seconds)
(2) Release button
Releasing radiation
◆ Use the button to release the exposure.
– Radiation is released in the selected operating mode.
– The current radiation parameters are displayed on the control panel of the
C-arm system.
During or at the end of the exposure, an acoustic warning signal sounds (can be
configured).
(1)
(2)

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
