Options
ARCADIS Varic
SPR2-310.620.30.02.02 23
of 24
Deleting the diaphragm positions 0
â—† If you wish to delete the stored diaphragm positions again, press one of the
diaphragm keys and the diaphragm will open completely when the cassette is
inserted.
Setting exposure data 0
If a cassette is loaded after the system is restarted, only dashes will be displayed
in the kV and mAs fields. You cannot release an exposure since this can only be
done after setting the required kV and mAs values.
â—† Now press one of the kV or mAs +/- buttons.
– The preference values 40 kV and 5 mAs will be displayed. You can then
change these values.
â—† Now press one of the kV or mAs +/- buttons until the required values are set.
– If you perform fluoroscopy in the meantime, the kV and mAs values used
for the last cassette exposure will remain set when reloading the cassette.
Example of kV and mAs values:
Display of kV values
Display of mAs values
kV
mAs
mA
