Operator Manual
78
of 78 SPR2-310.620.30.02.02
Image Processing
Configuring image text display 0
In the Image Text Configuration dialog you can set which image text informa-
tion is to be displayed by default with individual basic formats. The dialog box is
opened by clicking the Image Text Editor button in the syngo Configuration
Panel.
â—† In the View Name selection list, select the basic format for which your con-
figuration settings apply.
â—† Select either All Text or No Text.
– By default, all available image texts or no image text are/is displayed.
or
â—† Click on the option field Customized Text.
â—† Select the desired information in the left selection area.
– By default, the selected image texts are displayed.
All entries in the left selection area can be selected or deselected with the button
Select All or Deselect All.
To Next Page
