Documentation
ARCADIS Varic
SPR2-310.620.30.02.02 37
of 98
Image, text and graphic display 0
The layout of the film sheet defines the number and size of the segments on a
film sheet. In the Film Preview window and the Filming task card, you can
change the aspect ratio of individual images in your segments and define wheth-
er and how text and graphics are to be printed or exposed on film.
â—† Click the Images subtask card into the foreground.
—or—
â—† Call up the Film Properties dialog box.
– The settings of the currently selected images are displayed.
– The dots in the radio buttons are displayed gray if the settings of the
images are different.
