Siemens ARCADIS Varic Operator's Manual

Options
ARCADIS Varic
SPR2-310.620.30.02.02 21
of 24
Exposure grid
An exposure grid measuring the same as the cassette format can be inserted into
the cassette holder with the cassette.
The exposure grid is delivered with the cassette holder.
◆ Always insert the exposure grid up to the end stop in the cassette holder.
Attaching the cassette holder 0
3 1
2
Caution
Springs or pins not correctly attached.
Risk of injury if cassette holder becomes loose!
◆ Make sure the springs and pins (3) are securely locked in place.
◆ Ensure that both centering pins sit in the recesses.

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
