Technical Data
Unit data 0
Complete system 0
General data
3rd edition IEC 60601-2-28 For environmental conditions that fall within the specified values, no wait time is
required for radiation operation.
For environmental conditions that fall outside the specified values, a wait time of
one to twelve hours must be factored in for radiation operation, depending on the
location of the system.
Classification
Power requirements 100 V, 110 V, 120 V, 127 V, 200 V, 230 V, 240 V ±10%; 50/60 Hz ±1 Hz
Nominal rating 20 A to 127 V∼,15A from 200V∼ corresponds to nominal value of the slow-
blow fuse in the power input of the product
Internal line resistance Ri < 0.3 ohms at 100 - 127 V∼
Ri < 0.8 ohms at 200 - 240 V∼
Power consumption max. 2.5 kVA
Weight C-arm system approx. 235 kg
Monitor trolley with 2 monitors, approx. 190 kg (with PC and UPS)
Environmental conditions
for operation
Temperature range: +15 °C to +35 °C
Rel. humidity: 15% to 75%, non-condensing
Barometric pressure: 700 hPa to 1060 hPa
Environmental conditions
for transport
Temperature range: -20 °C to +37 °C
Rel. humidity: 10% to 95%, non-condensing
Barometric pressure: 700 hPa to 1060 hPa
Protection against electric
shock
Class 1, no applied part acc. to IEC 60601-1
Protection against ingress
of fluids
IPXO (not protected) acc. to IEC 60529
Operating mode Continuous operation
