Operator Manual
14
of 24 SPR2-310.620.30.02.02
Configuration
The Common tab card 0
On this tab card you define the parameters that apply to all operating programs
in each examination set.
Parameter settings You can change the following parameters on the tab card:
Changing parameters â—† Select the required new parameters from the selection lists.
â—† Click this button.
– Your changes are applied to the ARCADIS Varic system.
– The configuration dialog remains open for further entries.
â—† Continue configuring the next operating mode on the corresponding tab card.
—or—
â—† Click this button.
– The dialog box closes.
Parameters Remarks
Black Offset Native possible values: -200 to 900
Black Offset Native Metal possible values: -200 to 900
Auto Dose Adjustment
Auto Dose Adjustment Metal
