Operator Manual
6
of 24 SPR2-310.620.30.02.02
Configuration
Managing examination sets 0
The examination sets are assigned to medical application areas. Within each
application they are also assigned to special body regions. You will find the same
assignment pattern on the Examination task card in the Extended display
mode.
Medical application fields can additionally be licensed by options. The medical
application area 'Vascular', for instance, is tied to the 'SUB/Roadmap' option.
If the option is not activated, the Examination Set Configuration will not con-
tain a configuration card for this option, and the application area cannot be select-
ed in the Examination task card.
Displaying a list of examination sets 0
When editing examination sets, first select the medical application area and after-
wards the body region. All valid examination sets for this combination are shown.
Medical application
area
Each medical application area is represented by a tab card in the Examination
Set Configuration dialog window.
â—† Click on the tab of the required medical application area.
– The selected tab card is placed in the foreground.
