Operator Manual
6
of 52 SPR2-310.620.30.02.02
Examination
Menu bar 0
The user can access various functions using the menu bar. It opens when the
mouse cursor is moved to the upper edge of the monitor.
Status bar 0
System messages indicating the current state of the system or error messages
are displayed in the lower part of the control area.
NaviLink 2D
If the NaviLink 2D option is available in the system and communication between
the navigation system and the C-arm is activated, you can see the NaviLink 2D
icon in the status bar of the Examination task card.
The navigation system sends a message to the C-arm system signaling readiness
for receiving images. The C-arm system receives the message, identifies the
sending navigation system and responds. At this moment, communication
between the two systems is activated and the NaviLink 2D icon appears in the
status bar of the Examination task card. As soon as the communication connec-
tion is terminated, the NaviLink 2D icon disappears again.
Control area 0
The display of the control area and the availability of functions depends on the
selected display mode.
Depending on the display mode, the following data is displayed within the control
area:
❏ Information about the current patient
❏ Examination settings
❏ The current state of the ARCADIS Varic
