Siemens ARCADIS Varic Operator's Manual

Image Processing
ARCADIS Varic
SPR2-310.620.30.02.02 9
of 78
Image subtask card The Image subtask card shows tool keys for image editing (the Basic display
mode only has the first row of keys).
Switch brightness/contrast characteristic (LUT) to previous (–) and next (+)
Reduce (–) and increase (+) edge enhancement
Inverting gray-scale values
Reduce an image by factor 0.5
Enlarge an image by factor 2.0
Zoom or pan the image
Rotating an image

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
