Operator Manual
40
of 78 SPR2-310.620.30.02.02
Image Processing
Zooming with the
mouse
The left mouse key is used to select or deselect images and objects. However,
you can also switch over the function of the left mouse button to perform zoom-
ing and panning.
â—† Select Image > Zoom/Pan.
Or
â—† Click the Zoom/Pan button on the Image subtask card.
â—† Now position the mouse pointer in the outer area of an image.
– The cursor changes shape.
â—† Drag the mouse cursor up with the left mouse button pressed.
– The image is enlarged.
Or
â—† Drag the mouse cursor down with the left mouse button pressed.
– The image is reduced.
– As soon as you release the mouse button, the new zoom factor is applied
to all the selected images or the selected scope of action.
When zooming, make sure you do not accidentally click on a graphic element.
Otherwise, you would pan the graphic element and not the content of the image.
â—† Deselect Image > Zoom/Pan again.
—or—
â—† Click the relevant button again.
– The left mouse button is available for selecting images again.
