Siemens ARCADIS Varic Operator's Manual

Operator Manual
40
of 98 SPR2-310.620.30.02.02
Documentation
Setting the original
◆ Click the Original Image button.
Or
◆ Select the Original Image option in the Film Properties dialog box.
– The images are displayed in the segment in their original size (max. 1% tol-
erance), the dimensions on the screen and on the printout are the original
ones.
If it is not possible to display images in the Original Image aspect ratio (1:1
scale), a message is displayed and the Fit to segment option is selected instead.

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
