Operator Manual
16
of 24 SPR2-310.620.30.02.02
Configuration
Changing parameters â—† Select the required new parameters from the selection lists.
â—† Click this button.
– Your changes are applied to the ARCADIS Varic system.
– The configuration dialog remains open for further entries.
â—† Continue configuring the next operating mode on the corresponding tab card.
—or—
â—† Click this button.
– The dialog box closes.
Noise Reduction LIH Low Special noise reduction factor for
LIH image to guarantee appropriate
image quality even with short-time
release
off (no noise reduction)
k = 2, k = 4, k = 8 (noise reduction on
with selected k factor); with PFC for
pulse rates > 2 p/s only
Autostore off (no automatic storage)
last (last image is stored)
all (all images are stored)
Storage Rate f/s only if Autostore = all
Setting in frames/s
Autoloop Check box for activating automatic play-
back of a sequence of images at the end
of the exposure
Pulsed p/s Pulse rate; possible values for storage
rate depend on the set value
Dose Level Possible values: low, medium, high
Characteristic Curve Entries can be defined using the service
user interface
Bone Display Possible values: white, black
Parameters Remarks
