Agilent X-Series Signal Generators SCPI Command Reference 145
System Commands
Route Subsystem (:ROUTe)
Route Subsystem (:ROUTe)
HARDware:DGENerator:INPut:BPOLarity
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:INPut:BPOLarity POSitive|NEGative
:ROUTe:HARDware:DGENerator:INPut:BPOLarity?
This command configures the polarity of the TTL input signal at the BURST GATE IN connector.
POSitive refers to normal logic, while NEGative refers to inverted logic.
*RST POS
Key Entry Burst Gate In Polarity Neg Pos
Remarks
This command performs the same function as
“HARDware:DGENerator:IPOLarity:BGATe” on page 146.
HARDware:DGENerator:INPut:CPOLarity
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:INPut:CPOLarity POSitive|NEGative
:ROUTe:HARDware:DGENerator:INPut:CPOLarity?
This command configures the polarity of the TTL input signal at the DATA CLOCK connector.
POSitive refers to normal logic, while NEGative refers to inverted logic.
*RST
POS
Key Entry Data Clock Polarity Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:IPOLarity:CLOCk” on page 146.
HARDware:DGENerator:INPut:DPOLarity
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:INPut:DPOLarity POSitive|NEGative
:ROUTe:HARDware:DGENerator:INPut:DPOLarity?
This command configures the polarity of the TTL input signal at the DATA connector. POSitive refers
to normal logic, while NEGative refers to inverted logic.
*RST POS
Key Entry Data Polarity Neg Pos
Remarks
This command performs the same function as
“HARDware:DGENerator:IPOLarity:DATA” on page 147.
