Agilent X-Series Signal Generators SCPI Command Reference 367
Digital Signal Interface Module Commands
Digital Subsystem—Option 003 and 004 ([:SOURce])
sample.
NEG This choice selects a negative polarity. The frame marker is low for the first data
sample.
Example
:DIG:DATA:OUTP:POL:FRAM NEG
The preceding example selects a negative polarity for the frame marker.
*RST POS
Key Entry
Frame Polarity
:DIGital:DATA:OUTPut:QGain
Supported N5172B/82B with option 003 or 004 or both
:DIGital:DATA:OUTPut:QGain <value>
:DIGital:DATA:OUTPut:QGain?
This command adjusts the gain for Q data in the N5102A module. The adjustment does not affect the
I data.
The variable <value> is expressed as a percentage based on 100% being equivalent to a gain of 1.
The offset is an adjustment to the analog level that is represented by the digital sample. The analog
voltage is limited to a 16- bit data sample.
Example
:DIG:DATA:OUTP:QG 90
The preceding example sets the gain for Q data to 90%.
*RST +0.00000000E+000
Range 87.5 to 112.5%
Key Entry
Q Gain
