Agilent X-Series Signal Generators SCPI Command Reference 195
4 Analog Modulation Commands
This chapter provides SCPI descriptions for subsystems dedicated to analog commands common to all
Agilent MXG signal generator models. This chapter contains the following major sections:
• Amplitude Modulation Subsystem–Option UNT ([:SOURce]) on page 195
• Frequency Modulation Subsystem–Option UNT ([:SOURce]) on page 207
• Low Frequency Output Subsystem ([:SOURce]:LFOutput) on page 217
• Phase Modulation Subsystem–Option UNT ([:SOURce]) on page 227
• Pulse Modulation Subsystem–Option UNU and UNW and Option 320 ([:SOURce]) on page 237
Amplitude Modulation Subsystem–Option UNT ([:SOURce])
:AM[1]|2[:DEPTh]:EXPonential
Supported All Models with Option UNT
[:SOURce]:AM[1]|2[:DEPTh]:EXPonential <value>
[:SOURce]:AM[1]|2[:DEPTh]:EXPonential?
This commands sets the amplitude modulation depth in dB.
*RST +4.00000000E001
Range 0 to 40 dB
Key Entry AM Depth
Remarks Refer to :AM[:DEPTh]:STEP[:INCRement] command for setting the value associated
with UP and DOWN choices.
:AM[1]|2[:DEPTh][:LINear]
Supported All Models with Option UNT
[:SOURce]:AM[1]|2[:DEPTh][:LINear] <value><unit>|UP|DOWN
[:SOURce]:AM[1]|2[:DEPTh][:LINear]?
This commands sets the amplitude modulation depth in percent.
*RST +1.00000000Eï€001
Range 0.0 to 100%
Key Entry AM Depth
Remarks Refer to :AM[:DEPTh]:STEP[:INCRement] command for setting the value associated
with UP and DOWN choices.
