298 Agilent X-Series Signal Generators SCPI Command Reference
Arb Commands
Dual ARB Subsystem–N5172B/82B ([:SOURce]:RADio:ARB)
*RST 0
:RETRigger
Supported N5172B/82B
[:SOURce]:RADio:ARB:RETRigger ON|OFF|1|0|IMMediate
[:SOURce]:RADio:ARB:RETRigger?
This command enables or disables the ARB retriggering mode. The retrigger mode controls how the
retriggering function performs while a waveform is playing.
ON (1) This choice (Buffered Trigger) specifies that if a trigger occurs while a waveform
is playing, the waveform will retrigger at the end of the current waveform
sequence and play once more.
OFF (0) This choice (No Retrigger) specifies that if a trigger occurs while a waveform is
playing, the trigger will be ignored.
IMMediate This choice (Restart on Trigger) specifies that if a trigger occurs while a waveform
is playing, the waveform will reset and replay from the start immediately upon
receiving a trigger.
*RST ON
Remarks This command applies to the single trigger type only.
:RSCaling
Supported N5172B/82B
1 Trigger is armed and the Dual ARB is waiting for a trigger to start the play- back of the waveform
RUN
b
0 The Dual ARB waveform is not playing
1 The Dual ARB waveform is playing
MBS1
0 Multiple BBG synchronization is not waiting for a sync signal from the master
1 Multiple BBG synchronization is waiting for a sync signal from the master
MBS2
0 Multiple BBG synchronization is out of sync
1 Multiple BBG synchronization is in sync
a. The ARM bit remains 0 for the following trigger type selections:
FREE (Free Run) see page 303
RESet (Reset and Run) see page 303
IMMediate (Restart on Trigger) see page 298
GATE see page 302
b. For GATE triggering, the bit remains high for both states of the trigger signal.
Key Entry No Retrigger Buffered Trigger Restart on Trigger
Table 5-1 Low and High Bit Position Description
