Analog Modulation Commands
Low Frequency Output Subsystem ([:SOURce]:LFOutput)
Low Frequency Output Subsystem ([:SOURce]:LFOutput)
:AMPLitude
Supported All Models with Option UNT
[:SOURce]:LFOutput:AMPLitude <val><unit>
[:SOURce]:LFOutput:AMPLitude?
This command sets the amplitude for the signal at the LF OUTPUT connector.
*RST
0.00
Range 0.000VP–5.0VP
Key Entry LF Out Amplitude
:DUAL:FUNCtion2:AMPLitude:PERCent
Supported All Models with Options UNT and 303
[:SOURce]:LFOutput:DUAL:FUNCtion2:AMPLitude:PERCent <value><unit>
[:SOURce]:LFOutput:DUAL:FUNCtion2:AMPLitude:PERCent?
This command sets the amplitude of tone 2 of the internal dual function generator source as a
percent of the peak analog modulation amplitude. Tone 1 of the internal dual function generator
source will make up the remaining amplitude.
*RST 50.0
:DUAL:FUNCtion2:POFFset
Supported All Models with Options UNT and 303
[:SOURce]:LFOutput:DUAL:FUNCtion2:POFFset <value><unit>
[:SOURce]:LFOutput:DUAL:FUNCtion2:POFFset?
This command sets the phase offset in degrees or radians of tone 2 in relation to tone 1 of the
internal dual function generator source.
*RST 0.000 rad
:DUAL:FUNCtion[1]|2:FREQuency
Supported All Models with Options UNT and 303
[:SOURce]:LFOutput:DUAL:FUNCtion[1]|2:FREQuency <value><unit>
Range 0 to 100.0%
Key Entry LFOut Tone 2 Ampl % of Peak
Range - 6.290 to 6.290 rad
- 360.4 to 360.4 deg
Key Entry LF Out Tone 2 Phase Offset
