Agilent X-Series Signal Generators SCPI Command Reference 57
Basic Function Commands
List/Sweep Subsystem ([:SOURce])
This command sets the point trigger source for a list or step sweep event.
BUS This choice enables GPIB triggering using the *TRG or GET command, or
LAN and USB triggering using the *TRG command.
IMMediate This choice enables immediate triggering of the sweep event.
EXTernal This choice enables the triggering of a sweep event by an externally applied signal
at the TRIGGER IN connector.
INTernal This choice enables the triggering of a sweep event by an internal Pulse Video or
Pulse Sync signal.
KEY This choice enables triggering by pressing the front- panel Trigger hardkey.
TIMer This choice enables the trigger timer.
Example
:LIST:TRIG:SOUR BUS
The preceding example sets the trigger source to the instrument BUS.
*RST IMM
:LIST:TYPE
Supported All Models
[:SOURce]:LIST:TYPE LIST|STEP
[:SOURce]:LIST:TYPE?
This command toggles between the two types of sweep.
LIST This type of sweep has arbitrary frequencies and amplitudes.
STEP This type of sweep has equally spaced frequencies and amplitudes.
*RST STEP
Key Entry Sweep Type List Step
:LIST:TYPE:LIST:INITialize:FSTep
Supported All Models
CAUTION The current list sweep data will be overwritten once this command is executed. If
needed, save the current data. Refer to the :STORe:LIST command for storing list sweep
files.
[:SOURce]:LIST:TYPE:LIST:INITialize:FSTep
This command replaces the loaded list sweep data with the settings from the current step sweep data
points.
You can load only one sweep list at a time.
Key Entry Bus Free Run Ext Int Trigger Key Timer Trigger
