Agilent X-Series Signal Generators SCPI Command Reference 353
Digital Signal Interface Module Commands
Digital Subsystem—Option 003 and 004 ([:SOURce])
:DIGital:DATA:INPut:MDEStination:AAMPlitude
Supported N5172B/82B with option 004
:DIGital:DATA:INPut:MDEStination:AAMPlitude NONE|M1
:DIGital:DATA:INPut:MDEStination:AAMPlitude?
This command opens a menu in which you can select a marker to select the alternate amplitude
functionality.
Further setups need to be done in the Amplitude > Alternate Amplitude menu to use the functionality.
Example
:DIGital:DATA:INPut:MDES:AAMP M1
The preceding example routes marker 1 to Alternate Amplitude.
*RST None
Key Entry Alternate Amplitude
:DIGital:DATA:INPut:MDEStination:ALCHold
Supported N5172B/82B with option 004
:DIGital:DATA:INPut:MDEStination:ALCHold NONE|M1
:DIGital:DATA:INPut:MDEStination:ALCHold?
Opens a menu in which you can select a marker to enable the automatic leveling control (ALC) hold
function (or select None to disable the hold feature). The hold selection remains until you reconfigure
it, press the Preset hardkey, or cycle the signal generator power.
CAUTION Incorrect ALC settings can cause a sudden unleveled condition to occur. An unleveled
RF output can damage a DUT or connected instrument. Ensure that you set markers
such that the ALC obtains a sample that accounts for the high power levels within
the signal.
Example
:DIGital:DATA:INPut:MDES:ALCH M1
The preceding example routes marker 1 to ALC Hold.
*RST None
Key Entry ALC Hold
:DIGital:DATA:INPut:MDEStination:PULSe
Supported N5172B/82B with option 004
:DIGital:DATA:INPut:MDEStination:PULSe NONE|M1
:DIGital:DATA:INPut:MDEStination:PULSe?
