Agilent Technologies N5171B User Manual

Agilent X-Series Signal Generators SCPI Command Reference 241
Analog Modulation Commands
Pulse Modulation Subsystem–Option UNU and UNW and Option 320 ([:SOURce])
NOTE A power search is recommended for signals with pulse widths less than one microsecond.
Refer to :ALC:SEARch.
Example
:PULM:INT:PWIDth 100MS
The preceding example sets the pulse width to 100 milliseconds.
*RST 2.00000000E006
Range 20 nS to (pulse period - 10 nS)
Key Entry Pulse Width
:PULM:INTernal:TRAin:LIST:PRESet
Supported All with Options UNW and 320
[:SOURce]:PULM:INTernal:TRAin:LIST:PRESet
This command sets the list to a single row of 2us of On Time, 2us of Off Time, and a Repetition of
1. Refer to :PULM:INTernal:TRAin:ONTime and :PULM:INTernal:TRAin:OFFTime.
:PULM:INTernal:TRAin:OFFTime
Supported All with Options UNW and 320
[:SOURce]:PULM:INTernal:TRAin:OFFTime <value>,<value>
[:SOURce]:PULM:INTernal:TRAin:OFFTime?
This command sets the pulse off values for the current list of pulse train off times (where the RF
will be off). If this list is shorter than the other lists, then the last element will be repeated as
necessary to match the length of the On Time or the Repetition list. The query returns the count of
pulse cycle elements in the list of off times. Refer to :PULM:INTernal:TRAin:ONTime and
:PULM:INTernal:TRAin:REPetition.
The resolution for this setting is 10nS.
Example
:PULM:INT:TRA:OFFT 100NS,200NS,400E–9
The preceding example sets the pulse train off cycles to 100 nanoseconds, 200 nanoseconds, and 400
nanoseconds.
:PULM:INTernal:TRAin:OFFTime:POINts?
Supported All with Options UNW and 320
[:SOURce]:PULM:INTernal:TRAin:OFFTime:POINts?
This query returns the count of elements in the list of off times.
Range
120nS to 42S (Option UNU)
20nS to 42S (Option UNW)
