146 Agilent X-Series Signal Generators SCPI Command Reference
System Commands
Route Subsystem (:ROUTe)
HARDware:DGENerator:INPut:SPOLarity
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:INPut:SPOLarity POSitive|NEGative
:ROUTe:HARDware:DGENerator:INPut:SPOLarity?
This command configures the polarity of the TTL input signal at the SYMBOL SYNC connector.
POSitive refers to normal logic, while NEGative refers to inverted logic.
*RST
POS
Key Entry Symbol Sync Polarity Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:IPOLarity:SSYNc” on page 147.
HARDware:DGENerator:IPOLarity:BGATe
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:IPOLarity:BGATe POSitive|NEGative
:ROUTe:HARDware:DGENerator:IPOLarity:BGATe?
This command configures the polarity of the input signal at the BURST GATE IN connector. POSitive
refers to normal logic, while NEGative refers to inverted logic.
*RST POS
Key Entry Burst Gate In Polarity Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:INPut:BPOLarity” on page 145.
HARDware:DGENerator:IPOLarity:CLOCk
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:IPOLarity:CLOCk POSitive|NEGative
:ROUTe:HARDware:DGENerator:IPOLarity:CLOCk?
This command configures the polarity of the TTL input signal at the DATA CLOCK connector.
POSitive refers to normal logic, while NEGative refers to inverted logic.
*RST
POS
Key Entry Data Clock Polarity Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:INPut:CPOLarity” on page 145.
