148 Agilent X-Series Signal Generators SCPI Command Reference
System Commands
Route Subsystem (:ROUTe)
HARDware:DGENerator:OPOLarity:DATA
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:OPOLarity:DATA POSitive|NEGative
:ROUTe:HARDware:DGENerator:OPOLarity:DATA?
This command configures the polarity of the TTL output DATA OUT signal at the DATA OUT pin on
the rear panel AUX I/O connector. POSitive refers to normal logic, while NEGative refers to inverted
logic.
*RST
POS
Key Entry Data Out Polarity Neg Pos
Remarks
This command performs the same function as
“HARDware:DGENerator:OUTPut:DPOLarity” on page 149.
HARDware:DGENerator:OPOLarity:SSYNc
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:OPOLarity:SSYNc POSitive|NEGative
:ROUTe:HARDware:DGENerator:OPOLarity:SSYNc?
This command configures the polarity of the TTL output SYMBOL SYNC signal at the SYM SYNC OUT
pin on the rear panel AUX I/O connector. POSitive refers to normal logic, while NEGative refers to
inverted logic.
*RST
POS
Key Entry Symbol Sync Out Polarity Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:OUTPut:SPOLarity” on page 149.
HARDware:DGENerator:OUTPut:CPOLarity
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:OUTPut:CPOLarity POSitive|NEGative
:ROUTe:HARDware:DGENerator:OUTPut:CPOLarity?
This command configures the polarity of the TTL output DATA CLOCK OUT signal at the DATA CLK
OUT pin on the rear panel AUX I/O connector. POSitive refers to normal logic, while NEGative refers
to inverted logic.
*RST
POS
Key Entry Data Clock Polarity Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:OPOLarity:CLOCk” on page 147.
