Agilent Technologies N5171B User Manual

Agilent X-Series Signal Generators SCPI Command Reference 147
System Commands
Route Subsystem (:ROUTe)
HARDware:DGENerator:IPOLarity:DATA
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:IPOLarity:DATA POSitive|NEGative
:ROUTe:HARDware:DGENerator:IPOLarity:DATA?
This command configures the polarity of the TTL input signal at the DATA connector. POSitive refers
to normal logic, while NEGative refers the inverted logic.
*RST
POS
Key Entry Data Polarity Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:INPut:DPOLarity” on page 145.
HARDware:DGENerator:IPOLarity:SSYNc
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:IPOLarity:SSYNc POSitive|NEGative
:ROUTe:HARDware:DGENerator:IPOLarity:SSYNc?
This command configures the polarity of the TTL input signal at the SYMBOL SYNC connector.
POSitive refers to normal logic, while NEGative refers to inverted logic.
*RST POS
Key Entry Symbol Sync Polarity Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:INPut:SPOLarity” on page 146.
HARDware:DGENerator:OPOLarity:CLOCk
Supported N5172B with Option 653 or 655, N5182B with Option 656 or 657
:ROUTe:HARDware:DGENerator:OPOLarity:CLOCk POSitive|NEGative
:ROUTe:HARDware:DGENerator:OPOLarity:CLOCk?
This command configures the polarity of the TTL output Data Clock Out signal at the DATA CLK
OUT pin on the rear panel AUX I/O connector. POSitive refers to normal logic, while the NEGative
refers to inverted logic.
*RST
POS
Key Entry Data Clock Out Neg Pos
Remarks This command performs the same function as
“HARDware:DGENerator:OUTPut:CPOLarity” on page 148.
