324 Agilent X-Series Signal Generators SCPI Command Reference
Arb Commands
Multitone Subsystem–N5172B/82B ([:SOURce]:RADio:MTONe:ARB)
This command stores the current multitone waveform setup in the signal generator file system of
MTONE files.
Key Entry Store To File
:SETup:TABLe
Supported N5172B/82B
[:SOURce]:RADio:MTONe:ARB:SETup:TABLe <freq_spacing>,
<num_tones>,<phase>,<state>
[:SOURce]:RADio:MTONe:ARB:SETup:TABLe?
This command creates and configures a multitone waveform.
The frequency offset, power, phase, and state value are returned when a query is initiated. The
output format is as follows:
<frequency offset>,<p
ower>,<phase>,<state>
The variable <freq_spacing> is expressed in units of Hertz (Hz–MHz).
The variable <power> is expressed in units of decibels (dB).
<freq_spacing> (>2 tones): 1E1 to (Option 65x bandwidth (num_tones 1))
NOTE The Toggle State softkey has a different softkey path but the same SCPI command when
initializing the Multitone table (For the softkey path, refer to “:SETup:TABLe:ROW” on
page 326).
Remarks To set the frequency spacing, refer to “:SETup:TABLe:FSPacing” on page 325.
*RST
Ton
e <frequ
ency
offset>
<po
wer>
<phase>
<state>
Tone 1 - 35000 +0.00000000E+000 +0 +1
Tone 2 - 25000 +0.00000000E+000 +0 +1
Tone 3 - 15000 +0.00000000E+000 +0 +1
Tone 4 - 5000 +0.00000000E+000 +0 +1
Tone 5 +5000 +0.00000000E+000 +0 +1
Tone 6 +15000 +0.00000000E+000 +0 +1
Tone 7 +25000 +0.00000000E+000 +0 +1
Tone 8 +35000 +0.00000000E+000 +0 +1
Range <freq_spacing> (2 tones): 1E1 to Option 65x bandwidth
<num_tones>: 2–64
<phase>: 0–359
BBG_max_bandwidth:
653: 60 MHz
655: 120 MHz
656: 80 MHz
657: 160 MHz
Key Entry Freq Spacing Number Of Tones Toggle State
