58 Agilent X-Series Signal Generators SCPI Command Reference
Basic Function Commands
List/Sweep Subsystem ([:SOURce])
The maximum number of list sweep points is 3,201. When copying the step sweep settings over to a
list sweep, ensure that the number of points in the step sweep do not exceed the maximum list
sweep points.
Key Entry Load List From Step Sweep
:LIST:TYPE:LIST:INITialize:PRESet
Supported All Models
CAUTION The current list sweep data will be overwritten once this command is executed. If
needed, save the current data. Refer to the :STORe:LIST command for storing list sweep
files.
[:SOURce]:LIST:TYPE:LIST:INITialize:PRESet
This command replaces the current list sweep data with a factory–defined file consisting of one point
at a frequency, amplitude, and dwell time.
Key Entry Preset List
:LIST:WAVeform
Supported N5172B/82B
CAUTION The current list sweep data will be overwritten once this command is executed. If
needed, save the current data. Refer to the :STORe:LIST command for storing list sweep
files.
[:SOURce]:LIST:WAVeform <name>,<name>
[:SOURce]:LISt:WAVeform?
This command sets the waveform values for the current list waveform sequence.
NOTE Except for the sample clock rate, unspecified fields in the header result in the default
settings of the dual arb’s settings being used (i.e. not the current arb’s settings). The sample
clock rate must be specified for the file header of the waveform file being played. If the
sample clock rate is unspecified in the file header, the instrument generates a header error.
Example
:LIST:WAV "WFM1:RAMP_TEST_WFM","WFM1:SINE_TEST_WFM"
The preceding example loads the waveforms RAMP_TEST_WFM and SINE_TEST_WFM into the waveform
section of the List Table.
Remarks The setting enabled by this command is not affected by signal generator power–on,
preset, or *RST.
:LIST:WAVeform:POINts
Supported N5172B/82B
