8 Agilent X-Series Signal Generators SCPI Command Reference
SCPI Basics
SCPI Basics
Table 1- 3 shows the response for a given parameter type.
Numeric Parameters
Numeric parameters are used in both common and subsystem commands. They accept all commonly
used decimal representations of numbers including optional signs, decimal points, and scientific
notation.
If a signal generator setting is programmed with a numeric parameter which can only assume a finite
value, it automatically rounds any entered parameter which is greater or less than the finite value.
For example, if a signal generator has a programmable output impedance of 50 or 75 ohms, and you
specified 76.1 for the output impedance, the value is rounded to 75. The following are examples of
numeric parameters:
Table 1-3 Parameter and Response Types
Parameter Types Response Data Types
Numeric Real, Integer
Extended Numeric Real, Integer
Discrete Discrete
Boolean Numeric Boolean
String String
Definite Block
Arbitrary byte data
a
a.(i.e. text, binary, discrete, real, integer, etc.-).
100 no decimal point required
100. fractional digits optional
ï€1.23 leading signs allowed
4.56E<space>3 space allowed after the E in exponential
ï€7.89Eï€001 use either E or e in exponential
+256 leading + allowed
.5 digits left of decimal point optional
