Agilent X-Series Signal Generators SCPI Command Reference 381
Real–Time Commands
Custom Subsystem–Option 431([:SOURce]:RADio:CUSTom)
The following table shows the various data rates by modulation type when the internal data
generator is used.
The bits per symbol are determined by the modulation type:
5 5 bps 37.5 Mbps 50 Mbps 50 Mbps 50 Mbps
6 6 bps 37.5 Mbps 50 Mbps 50 Mbps 50 Mbps
7 7 bps 37.5 Mbps 50 Mbps 50 Mbps 50 Mbps
8 8 bps 37.5 Mbps 50 Mbps 50 Mbps 50 Mbps
9 9 bps 37.5 Mbps 50 Mbps 50 Mbps 50 Mbps
10 10 bps 37.5 Mbps 50 Mbps 50 Mbps 50 Mbps
Range
Bits/Symbo
l
Min Bit
Rate
N5172B Opt
653
Max Bit Rate
N5172B Opt
655
Max Bit Rate
N5182B Opt
656
Max Bit Rate
N5182B Opt
657
Max Bit Rate
1 1 bps 37.5 Mbps 75 Mbps 50 Mbps 100 Mbps
2 2 bps 75 Mbps 150 Mbps 100 Mbps 200 Mbps
3 3 bps 112 Mbps 225 Mbps 150 Mbps 300 Mbps
4 4 bps 150 Mbps 300 Mbps 200 Mbps 400 Mbps
5 5 bps 187 Mbps 375 Mbps 250 Mbps 500 Mbps
6 6 bps 225 Mbps 450 Mbps 300 Mbps 600 Mbps
7 7 bps 262 Mbps 525 Mbps 350 Mbps 700 Mbps
8 8 bps 300 Mbps 600 Mbps 400 Mbps 800 Mbps
9 9 bps 337 Mbps 675 Mbps 450 Mbps 900 Mbps
10 10 bps 375 Mbps 750 Mbps 500 Mbps 1000 Mbps
Bits/Symbo
l
Modulation Type
1 2- Lvl FSK, ASK, BPSK, MSK
2 4- Lvl FSK, 4QAM, C4FM, Gray Coded QPSK, IS95
OQPSK, IS95 QPSK, OQPSK, QPSK, pi/4 DQPSK,
Unbalanced QPSK
38-Lvl FSK, 8PSK, D8PSK, EDGE
4 16-Lvl FSK, 16PSK, 16QAM, VSA 16QAM
5 32QAM, VSA 32QAM
