Benelli TNT125 Service Manual

Replacing Brake Hose and Brake Pipe
Note
The brake fluid may quickly corrode the
surfaces of painted parts, therefore, if the brake
fluid splashes on any plastic part, it must be
thoroughly rinsed immediately.
●Remove the hollow bolt [A] of brake hose.
●When the brake hose is removed, do not splash the
brake fluid on any painted parts.
●When the brake hose [B] is removed, temporarily fix
the end of brake hose to a higher position to minimize
the loss of brake fluid.
●If the brake fluid spills, clear it immediately.
- 100 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
