Replacing Spark Plug
●Remove the ignition coil (see “Disassembling
Ignition Coil” in the “Electrical System” chapter).
●Remove the spark plug [A] vertically with the
wrench for spark plug.
Replace them with two new spark plugs.
Standard Spark Plug
Model: A7RC (BOSCH)
●Insert a new spark plug into the spark plug hole and
press the spark plug tightly with your finger.
●Use the wrench [A] for spark plug to tighten the
spark plug vertically.
Note
If the wrench is tilted when the spark plug is
tightened, the insulator of spark plug may be
broken.
Locking torque of spark plug: 13 N·m
●Fix the ignition coil firmly.
○Make sure that the fixed ignition coil is not easy to fall off.
- 117 -
