Benelli TNT125 Service Manual

Cleaning Motorcycle before Disassembly
Thoroughly clean the motorcycle before
disassembly. If dust or other foreign matters enter the
sealing area in the disassembly process, the excessive
wear will be caused and the performance of
motorcycles will be reduced.
Collecting and Cleaning Removed Part
The removed parts are easily confused. So
arrange the removed parts in accordance with the
disassembly order and reinstall the parts after they are
cleaned.
Storing Removed Part
After all parts (including subparts) are cleaned,
store the parts in a clean area. Cover the parts with a
clean cloth or plastic film to prevent any foreign
matters from falling into the parts before reassembly.
Check
The use of worn or damaged parts may lead to
major accidents. Visually check whether the removed
parts have been corroded, discolored or suffered other
damages. The use limits of individual parts are
described in the appropriate chapters of this Manual. If
any damage is found or the part has exceeded the use
limit, the part must be replaced.
- 22 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
