Handle Switch
Switch State (Non-Europe)
1. Lamp control switch
2. Flameout switch
3. Start switch
4. Dimmer switch
5. Steering switch
6. Horn switch
7. Overtaking switch
PASS
Yellow/Red
Orange/Blue
Red/White
Dark green
Green/Yello
w
Red
Dark green
Dimmer switch
Steering switch
Horn switch
Blue
Yellow/
Red
Light
blue
Red/Wh
ite
Green/B
lack
Green/
White
Black
Red/Wh
ite
Brown
