Benelli TNT125 Service Manual

Installing Grip End
●Check for clearance between the grip end [A] and slot
[B].
★ If there is a gap, please remove the grip end!
Warning
There is a gap between the grip end and the rim
edge, indicating that the grip end and/
or slot
hasexpanded. Therefore, loose grip end needs to
be repalced.
Do not reuse the grip end!
If the wheels are not balanced, dangers may be
caused when riding.
Grip End
Grip end
10 g （0.35 oz.）
20 g （0.71 oz.）
30 g （1.06 oz.）
Remark
○
Benelli dealers sell the balance weights of 10, 20
and 30 g (0.35, 0.71 and 1.06 oz) respectively. The
imbalance within 10g will not affect the driving
stability of the motorcycle.
○
Please do not use more than 4 weights (including 4,
total weight of more than 90 g/3.2 oz). If you need to
control the balance with the wheel of more than 4
weights, please disassemble the wheel to find the
cause of the problem.
- 293 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
