Benelli TNT125 Service Manual

Checking the time to turn on brake lamp
●
See the brake lamp switch operation inspection
section in the chapter of regular maintenance
Adjsuting the time to turn on brake lamp
●See the brake lamp switch operation inspection section in the chapter of regular maintenance
Switch Inspection
• Check whether only the connection in the table is
connected by using a handheld multimeter
○For the switch housing and main switch, see the table
in the circuit diagram section
★
If the switch is open-
circuited or short circuited,
repair it or replace it with a new one
Rear Brake Lamp Switch Connection
Rear brake lamp switch connection
Color BR BL
When the brake pedal is pressed
When the brake pedal is released
Side Stand Switch Connection
Side stand switch connection
Color BK G
When the side stand is pressed
When the side stand is released
- 459 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
