Benelli TNT125 Service Manual

Flywheel puller
●Remove the flywheel
Checking Magneto
●There are three types of magneto faults: short circuit,
open circuit (the wire is burned out) or magnetic loss of
rotor. A short or open circuit of coil will result in low
output or even no output. The magnetic loss of rotor
will result in low output, this loss may be caused by the
dropping or beating suffered by the AC generator, and it
may also caused because the rotor is placed near the
electromagnetic field, or due to the aging only.
- 432 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
