Replacing Rubber Parts of Calipers
Disassembling Front Calipers
●Before the front calipers are disassembled, drain the
front brake oil.
●Loosen the front calipers fixing screw [A] and hollow
bolt [B], and then gently unscrew them.
Disassemble:
Front calipers [C] (see “Disassembling Front Calipers”
in the “Brake” chapter),
Front brake pad (see “Disassembling Front Brake Pad”
in the “Brake” chapter),
Front calipers assembling bolt
O-ring seal
CBS type
- 109 -

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Benelli TNT125 and is the answer not in the manual?

Benelli TNT125 Specifications

General IconGeneral
Displacement125 cc
Transmission5-speed
Fuel SystemEFI
Fuel Capacity7.2 liters
Seat Height780 mm
Dry Weight116 kg
Bore x Stroke54 mm x 54.5 mm
Starting SystemElectric
Wheelbase1215 mm
Engine TypeSingle cylinder, 4-stroke, air-cooled
Front SuspensionUpside-down fork
Front BrakeSingle disc
Rear BrakeSingle disc
Front Tire120/70-12
Rear Tire130/70-12
Max Power8.2 kW (11.1 Cv) @ 9500 rpm
Rear SuspensionSwing arm with lateral shock absorber with adjustable spring preload
