Starter Mechanism

Disassembling Starter Mechanism

●Loosen left cover bolt

Note: Loosen the bolt in a criss-cross

form, and loosen

the bolt by 1/4 each time and then remove the left cover

●Remove starter gear wheel and idle gear components,

and loosen flywheel lock nut using electric tools,

Left cover

mounting bolt

Starter gear

wheel

Idle gear

- 273 -

lock nut
