Clutch Cable
Make clutch cable go
through the right clamp
of head, and go into the
frame from here
Make clutch wire
walk down along the
front of iginition coil
Clamp the clutch cable
and o
xygen sensor
cable and rectifier
plug
-in cable with a
iron clamp
Clamp oxygen sensor
cable and rectifier
plug
-in cable with a
frame clamp
Make clamp pass
through the clamp
- 471 -
