Benelli TNT125 Service Manual

Technical Parameters
Item Standard
Front shock absorber (each one)
Diameter of front shock absorber
inner pipe
Pressure
φ35 mm
Pressure
Front shock absorber oil:
Viscosity
Oil quantity
Free length of front shock absorber
spring
Atmospheric pressure (unadjustable)
22# shock absorber oil
20 (at the temperature of 20℃)
315 ±2ml (after the disassembly, the oil has been drained completely)
245 mm (lower use limit: 80.9mm) (maximum deformation: 164.1)
Rear shock absorber
Spring prepressing setting: Double-nut adjustment
Standard Spring length: 141 mm
Applicable scope Spring length: 141 ~80.8mm
(From weak to strong)
- 341 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
