Benelli TNT125 Service Manual

Installing Tire
Warning
Front and rear wheels must be the products
of the same manufacturer!
●Check rims and tires and replace them if necessary.
●Clean the sealing surfaces of rims and tires, and make
the sealing surface of rim smooth using a fine abrasive
cloth if necessary.
●Remove and discard the air inlet valve.
Note
Air inlet valve must be replaced when changing
tire! Please do not use it repeatedly!
●Install a new air inlet valve at rim.
○Remove air inlet valve cap, apply soap or rubber
lubricant at seal of valve stem [A], pull out [B] air
outlet valve stem from the inside of rim, and adjust the
place of valve stem.
Note
Do not use oil or gasoline distillate as lubricant of
valve stem, because oil or gasoline distillate may
rot rubber.
○The structure of valve is shown in the figure.
Air inlet valve cap [A],
Air inlet valve [B],
Valve stem seal [C],
Valve stem [D]
Air inlet valve seat [E],
Opening air inlet valve [F]
●
Check the tire rotation marks on the front wheel tire
and the rear wheel tire, and then install the tires on the
corresponding rim.
Tire rotation mark [A]
Rotation direction [B]
- 296 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
