Benelli TNT125 Service Manual

★
If the measured result does not meet the specified
valve, adjustment shall be carried out.
○Adjust the free travel of brake pedal.
1. Loosen the nut [B] on joint [A].
2. Screw in or screw out the mandril [C] to adjust the
free travel of brake pedal.
If the mandril [C]
is screwed in, the free
travel will be reduced;
If the mandril [C] is screw out, the free travel
will be increased
3. When the free travel meets the s
pecified value,
tighten and fasten the nut [B].
4. After adjustment, the brake dragging phenomenon
shall be avoided.
Checking Brake
●Ride the motorcycle on the dry road and check
whether the front and rear brakes are normal.
★If the brake is abnormal, check the brake system.
Warning
If you need to test the motorcycle in the
checking process, make sure to ride it in the
place with safe traffic conditions.
Checking Brake Fluid Level
●
Check front brake fluid, and ensure whether the level
of brake fluid in the pump [B] is above the lower limit
oil lens [A].
Remark
○When checking the brake fluid level, rotate the
handle to keep the reservoir level.
- 73 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
