Benelli TNT125 Service Manual

Ball Bearing and Needle Bearing
If
not necessary, do not remove the ball or needle in
the bearing. Once the ball or needle is removed, it must be
replaced with a new one. When pressing the bearing, note
that the manufacturer and size signs shall be placed
outward. Apply force to the correct bearing race (as
shown in the figure) and press the bearing in place.
If the force is applied to the wrong bearing race, the
stress on inner ring and outer ring will produce, which
will damage the bearing.
Oil Seal and Grease Oil Seal
If not necessary, do not remove the oil seal or grease
oil seal which has been tightly sealed. Once it is removed,
it must be replaced with a new one. When pressing the
new oil seal, note that the manufacturer and size signs
shall be placed outward. Make sure that the oil seal is
correctly positioned.
Apply
the grease on the edges of oil seal in
accordance with the specified quantity before it is
installed.
- 26 -
Grease

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
