Disassembling Engine
●Support the rear part of swing arm with a bracket.
●Grasp the brake lever slowly and bind it with a tape.
Warning
The brake lever must be grasped when
disassembling the engine, o
therwise the
motorcycle will topple, which will cause accidents
and personal injury.
●Drain the oil (see “Regular
Maintenance”—“Replacing Oil”),
●Drain the coolant (see “Regular
Maintenance”—“Replacing Coolant”);
●Disassemble:
Seat cushion (see “Frame”—“Disassembling Seat
Cushion”)
Guard (see “Frame”—“Disassembling Guard”),
Fuel tank (see “Fuel Injection System
(EFI)”—“Disassembling Fuel Tank”),
Muffler (see “Frame”—“Disassembling Muffler”),
Drive chain (see “Drive”—
“Disassembling Drive
Chain”)
Drain the oil (see “Regular Maintenance”—“Replacing
Oil”),
●Loosen the nut [A] and remove the clutch cable
connector [B]
●Loosen the nut [A] and remove the throttle cable
connector [B]
- 409 -
