Benelli TNT125 Service Manual

Side Stand
Disassembling Side Stand
●Lift the rear wheel above the ground by using the
bracket.
●Disassemble:
Side stand spring [A]
Nut [B],
Side stand bolt [C]
Side stand [D]
Installing Side Stand
●Apply the grease to the moving part of side stand [D].
●Apply the thread fastening glue to the thread of side
stand bolt [C].
●Tighten the bolt and lock it with the nut [B].
Locking torque:
Side stand bolt [A]: 50 N·m
Side stand bolt lock nut [B]: 45 N·m
●Install the spring [D] to enable the longer end to face
up.
- 398 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
