Benelli TNT125 Service Manual

Replacement Part
Replacing Air Filter Element
Remark
○If the motorcycle is used in a dusty environment,
the replacement interval of air filter element shall
be sh
orter than the recommended replacement
interval.
○After riding in rainy days or on muddy roads,
replace the air filter element immediately.
Warning
If any dirt or dust enters into the throttle
body assembly, the throttle may be blocked and
safety accidents may be caused.
Note
If the dirt enters into the engine, the excessive
wear of engine may be caused, or even the
engine may be damaged.
●Remove the front seat cushion [A] using key [B]
●Disassemble:
Remove the fixing screw [A]
Remove the air filter air inlet [B]
- 94 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
