Benelli TNT125 Service Manual

Take the air cleaner element [A].
★Checking:
Check whether the filter element is polluted or
damaged.
Please replace with a new one if it has been polluted or
damaged.
★Cleaning:
Rinse the filter element softly and thoroughly with
cleaner.
Then apply the oil to the filter element and then
squeeze out the redundant oil, so that the filter element
is moist without oil dripping.
Remark
○Do not use the gasoline so as not to cause fires.
○Do not distort or warp the filter element so as not
to damage the foam materials.
●Install a new filter element [5].
Note
The recommended air filter element (Benelli
part number: 49202N220002) must be used. If
other air filter elements are used, the engine will
be worn prematurely or the performance of
engine will be reduced.
●Carry out the installation and disassembly in a reverse
process.
●Tighten air filter air inlet screw
●Reinstall the removed parts.
- 95 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
