Benelli TNT125 Service Manual

Technical Parameters
Item
Standard
Operating limit
Free corner of clutch operating lever 10°-20° —
Free length of clutch spring 35.5 34.2
Thickness of clutch friction 2.9-3.0 2.6
Wraping of clutch metal plate — 0.3
Inner diameter of clutch bushing 17-17.018 17.028
Outer diameter of clutch bushing 22.967-22.98 22.957
Torque Value
Clutch lock nut 50N•m Apply oil to threads
Clutch spring bolt
10N•m
Right cover mounting bolt 12N•m
Oil filter mounting bolt 12N•m
Mounting bolt at
shock-insulation rubber retainer
of right cover
9N•m
- 244 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
