Benelli TNT125 - Disassembly of Fuel Tank

Disassembly of Fuel Tank
●Disassemble front seat cushion (refer to
“Frame”-“Disassembling Front Seat”)
● Disassemble fuel tank cover(refer to
“Frame”-“Disassembling Fuel Tank Cover”)
●Disassemble rear mounting bolt of fuel tank [A]
●Disassemble front mounting bolt of fuel tank [A]
●Remove the connecting pipe [A] between fuel tank
and check valve
●Disassemble the check valve [B]
- 136 -
