Switch, Sensor and Other Parts
Power Lock Switch
Disassembling power lock
●Remove the fairing (see “Frame” – “Disassembling
Cowling” for details).
●Remove the main switch lead connector.
Power Lock Inspection
●Check the continuity of connector terminal.
★
If the result does not comply with the continuity
table, please replace the main switch
Wire color
Position
R R/W
- 455 -
