Benelli TNT125 Service Manual

Engine Cylinder Head and Cylinder Head Cover
Checking Valve Clearance
Remark
○Valve clearance can be checked and adjusted only
when the engine is cooled (to the indoor
temperature).
●Disassemble:
Remove the seat cushion (see “Disassembling Seat
Cushion” in “Frame” chapter),
Remove the fuel tank (see “Dis
assembling Fuel Tank”
in “Fuel Tank” chapter),
●
Disassemble the fixing screw [A], remove the
cylinder head hose [B] and cylinder head cover [C]
●Disassemble:
Left cover accessing screw [A]
Left rear cover [B]
- 61 -

Benelli TNT125 Specifications

General

Displacement	125 cc
Transmission	5-speed
Fuel System	EFI
Fuel Capacity	7.2 liters
Seat Height	780 mm
Dry Weight	116 kg
Bore x Stroke	54 mm x 54.5 mm
Starting System	Electric
Wheelbase	1215 mm
Engine Type	Single cylinder, 4-stroke, air-cooled
Front Suspension	Upside-down fork
Front Brake	Single disc
Rear Brake	Single disc
Front Tire	120/70-12
Rear Tire	130/70-12
Max Power	8.2 kW (11.1 Cv) @ 9500 rpm
Rear Suspension	Swing arm with lateral shock absorber with adjustable spring preload
